– General OutputRated Power:10,000W(10kW)

– Peak Power: 15kW – 20kW (surge)

– Output Voltage: 230V (single-phase) or 120/ 240V split phase .

– Frequency: 50/60Hz

– Waveform: Pure sine waveTransfer Time: ~ 10ms

– Battery Side System Voltage: 48V

-Battery Range: 40–60V DC

– Battery Types: Lithium / Lead-acid / User defined

– Max Charging Current:Solar: 200AGrid/ Generator: 120A

-Solar (PV Input)MPPT Trackers: 2 (dual MPPT)

– Max PV Power: 11,000W (5.5kW × 2)

– Max PV Voltage (Voc): 500V DCMPPT

– Voltage Range: 125 – 425V DCMax Input Current: 22A + 22A

– Grid / GeneratorInput Voltage Range: 90 – 270V ACSupports hybrid operation (PV + battery + grid)

– Performance MPPT Efficiency: 99.9%

– Inverter Efficiency: 92%Motor Capacity: Up to 6HP

– Communication & ExtrasPorts: RS485 / CAN / USB / Dry contactOptional: WiFi / GPRS Monitoring

– Parallel capability: Up to 6 units

– Physical weight: ~21–29 kg

– Protection: IP20
